Wholesale 20 Amp Duplex GFCI Outlet with Safety Shutters and LED Self-Test Function, Residential Grade LD-3008B-red-black Supplier, Suppliers

1. A GFCI can directly replace a standard electrical outlet and be installed in place of an old outlet without any modifications to the wiring.

2. Tamper-Resistant: Automatic shutter system prevents young children from inserting unwanted objects into the outlets

3. Certificationï¼šETL/cETL

Send Inquiry

Product Description

Product Specifications

Part No.	LD-3008B (Red and Black Button)
Description	20 Amp Duplex GFCI Outlet with Safety Shutters and LED Self-Test Function, Residential Grade
Color	White, Ivory, Black, Grey, Brown.
Amp	20Amp
Volt	125V AC
Hertz	60Hz
NEMA	5-20R
Pole	2
Wire	3
Termination	Back and side 20Amp feed-thru
Face material	Thermoplastic
Body material	Thermoplastic
Strap material	Steel
Standards & Certifications	ETL/cETL

Key Features

Constructed with premium high-impact resistant thermoplastic materials and rational structure design, ensures superior strength and durability.

Green LED Indicator: Know the GFCI working status at a simple glimpse.

Provides continuous ground fault protection - detects and trips on actual ground fault even when self-test is being conducted.

Advanced Self-Detection: The device starts detection 30 minutes after power-on, and automatically performs self-tests every 3 hours to ensure safety.

Frequently Asked Questions

1. What does the green LED indicator signify?

The green LED indicator provides a quick visual confirmation that the GFCI is functioning correctly and the outlet is powered.

2. How often does the GFCI perform a self-test?

The device performs its first self-test 30 minutes after being powered on. Subsequently, it automatically conducts a diagnostic test every 3 hours.

3. What happens if the self-test detects a failure?

If a failure is detected, the device will either cut off the output power or illuminate the red indicator light to alert you of the fault.

4. Is this outlet suitable for high-traffic residential areas?

Yes, it is residential grade and constructed from high-impact resistant thermoplastic, designed for superior strength and long-term durability.

5. What is the NEMA rating for this outlet?

This product features a NEMA 5-20R rating, suitable for 20 Amp and 125V AC configurations.

6. Does it provide protection during the self-test process?

Yes, the device provides continuous ground fault protection and can detect and trip on actual faults even while a self-test is in progress.
